TIG780-12 High Thermal Conductivity Silicone Heat Transfer Grease
The TIG™780-12 is environmentally safe silicone-based thermal
grease designed to solve overheating and reliability issue.
TIG™780-12 is presenting thermal paste products. They serve to
moisten the contact surface sufficiently so as to form an interface
of extremely low thermal impedance.Consequently, the heat
dissipation efficiency is farsuperior to that offered by others.
Features
> Good thermal conductivity
> Low thermal resistance
> Non-toxic and environmentally safe
> Outstanding electrical insulation properties
> Thoroughly wets out contact surfaces to create low thermal
resistance
> Excellent long term stability
Applications
> Semiconductor cases and heat sinks.
> Power resistors and chassis, thermostats and mating surfaces,
and thermoelectric cooling devices.
> CPU's and GPU's.
> Memory Modules
> Mass storage devices
> Automotive electronics
> Set top boxes
> Audio and video components
Typical Properties of TIG™780-12 Series |
| Product Name | TIGTM780-12 | Tese Method |
| Color | White paste | Visual |
| Construction & Compostion | Metal oxide filled silicone oil | Ziitek Test Method |
| Viscosity | 1000K (Pa.s @.25℃) | Brookfield DV2T |
| Bond line Thickness | 0.012 | ASTM D374 |
| Specific Gravity (g/cm3) | 2.5 | ASTM 2240 |
| Continuos Use Temp | -45℃ to 200℃ | Ziitek Test Method |
| Evaporation (TML)(200℃@24hrs) | 0.23% | ASTM E595 |
| Thermal Conductivity | 1.2W/mK | ASTM D5470 |
| Thermal Impedance(℃-in²/W )@ 50 psi | 0.065 | ASTM D5469 |
Packing details:
TIGTM780-12 Series is available in 300ml/can,
1kg (pint container),3kg (quart container),
and 10kg(gallon container),
or custom packaged in syringes for automated applications.
Storage:
Store from 20C to 35°C with a maximum humidity of 50%. Do not store
in freezer orrefrigerator below 10°℃.
Company profile
With professional R&D capabilities and over 19 year experiences
in thermal interface material industry, Ziitek company own many
unique formulations which are our core technologies and advantages.
Our goal is to provide quality & competitive products to our
customers worldwide aiming for long-term business cooperation.
Independent R&D team
