TIG780-56 Thermal grease CPU thermal paste low thermal resistance
environmentally friendly silicon paste
The TIG™780-56 is environmentally safe silicone-based thermal
grease designed to solve overheating and reliability issue.
TIG™780-56 is presenting thermal paste products. They serve to
moisten the contact surface sufficiently so as to form an interface
of extremely low thermal impedance.Consequently, the heat
dissipation efficiency is farsuperior to that offered by others.
Features
>Low thermal resistance of 0.005 ℃-in²/w
>Non-toxic and environmentally safe
>Excellent long term stability
>Thoroughly wets out contact surfaces to create low thermal
resistance
Applications lnclude
>Display card
>Mainboard/mother board
>Notebook
>Power supply
>Heat pipe thermal solutions
>Memory Modules
>Mass storage devices
>Automotive electronics
>Set top boxes
| Typical Properties of TIG™780-56 Series |
| ProductName | TIG™780-56 | Test Method |
| Color | Gray | Visual |
| Construction &Compostion | Metal oxide filled silicone oil | ***** |
| Viscosity | 3700K cps @ 25℃ | Brookfield RVF,#7 |
| Specific Gravity | 2.3 g/cm³ | ASTM D2240 |
| Continuous Use Temp | -45℃ to 200℃ | ***** |
| Evaporation(TML) | 0.18% / 200℃@24hrs | ASTM E590 |
| Thermal Conductivity | 5.6 W/mK | ASTM D5470 |
| Thermal lmpedance | 0.005℃-in²/W @ 50 psi | ASTM D5470 |
Package
TIG™780-56 Series is available in 1kg (pint container), 3kg (quart
container), and 10kg(gallon container).
Storage:
Store from 20°C to 35°C with a maximum humidity of 50%. Do not
store in freezer or refrigerator below 10°C.
Company profile
Ziitek company is a manufacturer of thermal conductive gap fillers, low melting
point thermal interface materials, thermal conductive insulators,
thermally conductive tapes, electrically & thermally conductive
Interface pads and thermal grease,Thermal Conductive
plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials
products, with well-equipped testing equipment and strong technical
force.
FAQ:
Q: Are you trading company or manufacturer ?
A: We are manufacturer in Vietnam.
Q: How long is your delivery time?
A: Generally it is 3-7 work days if the goods are in stock. or it
is 7-10 work days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra cost?
A: Yes, we could offer samples free of charge.
